Product Details
Place of Origin: WUXI JIANGSU CHINA
Brand Name: HENGYUAN
Certification: CE,UL
Model Number: Cordierite Ceramics
Payment & Shipping Terms
Minimum Order Quantity: 100
Price: Negotiable
Packaging Details: Carton
Delivery Time: 20 DAYS
Payment Terms: Negotiable
Supply Ability: 5000 PCS/WEEK
|
Material:
|
Cordierite Ceramics
|
Color:
|
Customizable
|
Hardness:
|
800 HV
|
Bending Strength:
|
900 Kgf/cm2
|
OEM，ODM:
|
Acceptable
|
Orgin:
|
WUXI JIANGSU CHINA
|
MOQ:
|
100 PCS
|
Package:
|
Carton
|
|
Material:
|
Cordierite Ceramics
|
|
Color:
|
Customizable
|
|
Hardness:
|
800 HV
|
|
Bending Strength:
|
900 Kgf/cm2
|
|
OEM，ODM:
|
Acceptable
|
|
Orgin:
|
WUXI JIANGSU CHINA
|
|
MOQ:
|
100 PCS
|
|
Package:
|
Carton
|
| Material | Cordierite Ceramics |
| Color | Customizable |
| Hardness | 800 HV |
| Bending Strength | 900 Kgf/cm² |
| OEM/ODM | Acceptable |
| Origin | Wuxi Jiangsu, China |
| MOQ | 100 PCS |
| Package | Carton |
Cordierite ceramic is a low expansion special ceramic with 2MgO*2Al₂O₃*5SiO₂ as the main component, featuring excellent thermal stability, low dielectric constant and superior thermal shock resistance. Its near-zero thermal expansion coefficient allows it to withstand drastic temperature changes without cracking, making it ideal for electronic substrates, catalytic carriers and high-temperature filters.
| Item | Test Condition | Unit & Symbol | Value |
|---|---|---|---|
| Main Chemical Composition | MgO, Al₂O₃, SiO₂ | ||
| Bulk Density | gm/cc | 2.6 | |
| Maximum Use Temperature | °C | 1400 | |
| Hardness | HV | 800 | |
| Bending Strength | 20°C | Kgf/cm² | 900 |
| Compressive Strength | 20°C | Kgf/cm² | 3500 |
| Thermal Expansion | 1×10⁻⁶/°C | ≤2.0 | |
| Thermal Conductivity | 25°C-30°C | W/m·k | 1.3 |
| Dielectric Constant | 1MHz, 25°C | 6 | |
| Volume Resistivity | 20°C | ohm-cm | > 10¹² |
