800 HV Hardness Cordierite Ceramics For Industrial Grade Applications

Name: 800 HV Hardness Cordierite Ceramics For Industrial Grade Applications
Brand: Yixing Hengyuan Ceramic Technology Co., Ltd.
SKU: Cordierite Ceramics
Availability: InStock

Product Details

Place of Origin: WUXI JIANGSU CHINA

Brand Name: HENGYUAN

Certification: CE,UL

Model Number: Cordierite Ceramics

Payment & Shipping Terms

Minimum Order Quantity: 100

Price: Negotiable

Packaging Details: Carton

Delivery Time: 20 DAYS

Payment Terms: Negotiable

Supply Ability: 5000 PCS/WEEK

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                800 HV Cordierite Ceramics, Industrial Cordierite Ceramics, 3500 Kgf/cm2 Cordierite Ceramic


Material:	Cordierite Ceramics	The Main Chemical Ingredient:	MgO, Al2O3,SiO2
Hardness:	800 HV	Compressive Strength:	3500 Kgf/cm2
OEM，ODM:	Acceptable	Orgin:	WUXI JIANGSU CHINA
MOQ:	100 PCS	Package:	Carton

Material:	Cordierite Ceramics
The Main Chemical Ingredient:	MgO, Al2O3,SiO2
Hardness:	800 HV
Compressive Strength:	3500 Kgf/cm2
OEM，ODM:	Acceptable
Orgin:	WUXI JIANGSU CHINA
MOQ:	100 PCS
Package:	Carton

800 HV Hardness Cordierite Ceramics For Industrial Grade Applications

Product Specifications

Material	Cordierite Ceramics
The main chemical ingredient	MgO, Al2O3,SiO2
Hardness	800 HV
Compressive Strength	3500 Kgf/cm2
OEM，ODM	Acceptable
Origin	WUXI JIANGSU CHINA
MOQ	100 PCS
Package	Carton

Product Description

Cordierite is a natural mineral with limited natural reserves. Currently, cordierite is primarily obtained through artificial synthesis. While traditional preparation methods involve solid phase sintering, modern techniques have evolved to include sol-gel methods, molten glass processes, and low-temperature combustion synthesis.

Item	Test Condition	Unit & Symbol	Cordierite Ceramics
The main chemical ingredient			MgO, Al2O3,SiO2
Bulk Density		gm/cc	2.6
Maximum Use Temperature			1400℃
Hardness		HV	800
Bending Strength	20℃	Kgf/cm2	900
Compressive Strength	20℃	Kgf/cm2	3500
Fracture Toughness	K(I c)	Mpa m1/2	-
Thermal expansion		1X 10-6/℃	≤2.0
Thermal conductivity	25℃-30℃	W/m.k	1.3
Thermal Shock Resistance	Tc	℃	250
Dielectricity constant	1MHz.25℃		6
Dielectric strength		ac-kV/mm (ac V/mil)	10
Volume Resistivity	20℃	ohm-cm	> 1012
